MS776

MS776

Feature

  • Support IoT Sensors

    Includes an extension board with modular design that supports various kinds of RF and sensor modules.

  • Edge Computing

    Able to pre-process collected data locally, closer to the source, before sending it to the data centre or cloud, which can greatly reduce latency.

  • Industry 4.0

    Designed with cloud connectivity and fieldbus accessibility, which allows implementation of real-time remote machine monitoring, predictive maintenance and other industry 4.0 scenarios.

Specifications

  • OS
  • Linux Yocto
  • CPU
  • ARM Cortex A9 CPU
  • Memory
  • 2GB DDR3
  • Storage
  • 8GB eMMC
  • Wireless Connection
  • WLAN 802.11 ac/a/b/g/n, Bluetooth 4.2 + BLE, LTE Cat 4, LAN, (Option extensibility) Wireless IoT sensor,  Cellular LPWA (LoRa, Wi-SUN En Ocean), GPS, GNSS
  • I/O Interface
  • UART RS232, USB 2.0, Micro SIM card slot *1, Micro SD card slot *1
  • Power
  • 12~24V
  • IP Protection
  • IP40
  • Environment
  • Operating temp -20C to 70C
