MS762E

MS762E

MS762E

Feature

  • Industrial/Commercial-grade Solution

    We are capable of offering industrial/commercial grade solution, which can be applied to various applications like self-order system, self-payment kiosk and industry 4.0 machine.

  • Wall Mount Display

    It is powered via PoE system, and based on Ethernet structure to communicate with the main gateway and deliver control signal to slave devices.

  • Customized HMI

    We offer design and manufacture service based on different requirements.

Specifications

  • OS
  • Android
  • CPU
  • ARM Cortex A9 1GHz
  • Memory
  • 2G DDR3
  • Storage
  • 32G eMMC
  • Display
  • 7-inch LCD, capacitive touch
  • Communication
  • Ethernet, PoE
  • I/O Interface
  • USB 2.0 x 1
    Micro USB x 1
    Etherent X 1 (PoE 802.3af)
    DC JACK 24V
  • Sensor
  • Ambient light sensor
  • Speaker
  • Stereo speaker
  • Microphone
  • Condencer MIC
  • Environment
  • Operating temp 0℃ to 40℃
    Storage temp -10℃ to 65℃
