MS769

MS769

MS769

MS769

Feature

  • Thinnest and Lightest Rugged Tablet

    It's thin and light, but with the durability and reliability you would expect from a rugged vehicle tablet.

  • In-cab & Portable Use

    With vehicle dock and removable battery design, it's able to support vehicle power input, offer rich I/O ports and operate either inside or outside the cab as a rugged mobile computer.

  • Multiple Connectivity Options

    With WLAN, Bluetooth, NFC, LTE connectivity options, it is ideally suited to deliver and support value-added functions like fleet management, dispatch, logistics, etc.

Specifications

  • CPU
  • ARM Cortex A53 1.5GHz
  • Memory
  • 2G DDR3
  • Storage
  • 16G eMMC
  • Communication
  • Wi-Fi, Bluetooth, NFC, GPS , LTE (vehicle dock option)
  • RF
  • WLAN, Bluetooth, NFC, LTE
  • Sensor
  • 3-Axis Accelerometer, Gyro meter, Light sensor
  • I/O Interface
  • USB 2.0 (host), Micro USB B (slave), POGO pin (9-32V vehicle power input, video input, audio out, RS-232, audio control, USB)
  • Camera
  • Front 5M, Rear 8M with LED flash
  • Battery
  • 2700mAh @ 3.7V recharagable battery
  • Button
  • Power/Home/Menu/Back/Volume Up & Down/Reset
  • Audio
  • Speaker, microphone
  • Environment
  • Operating temp 0°C to +50°C Storage temp -20°C ~ 70°C
  • IP level
  • IP54
