MS765

MS765

Feature

  • Outdoor Multifunctional Display

    It's a multifunctional display, which can build with different communication protocol and work with different types of vehicles, like agriculture tractor and construction machine.

  • Large Size & Sunlight Readable LCD

    It's the best rugged Android tablet solution for outdoor use with the 12" large size, 1,000nits high brightness LCD and IP67 protection level.

  • Metal Housing

    It's designed with a elegant aluminum die casting housing.

Specifications

  • OS
  • Android
  • CPU
  • ARM Cortex A9 1GHz
  • Memory
  • 2G DDR3
  • Storage
  • 32G eMMC
  • Display
  • 12.1-inch LCD, 1000nits, viewing angle +/- 85° - horizontal (L/R) and vertical (U/D), UV resistance
  • Communication
  • Ethernet/Wi-Fi/Bluetooth
  • I/O Interface
  • DC power input x 1
    Ethernet x 2
    Serial Expansion Connector x 1
    CAN Expansion Connector x 1
    USB Port x 2
  • Camera
  • 5M pixel (front)
  • Power
  • 9~32V
  • Sensor
  • Temperature sensor
  • Speaker
  • Build-in speaker 3W x 1
  • Button
  • Power
  • Housing
  • Aluminum
  • Environment
  • Operating temp -20℃ to 60℃
    Storage temp -30℃ to 75℃
  • IP level
  • IP67
