MS761

MS761

Feature

  • Vehicle Diagnostic

    It's able to collects data and gives the drivers, fleet owners or repair technicians access to the status of the vehicle.

  • Fleet Management

    It collects data and delivers the information via Wi­Fi or LTE network to obtain vehicle and positional information and runs fleet management applications.

  • Fixed Mount Vehicle Tablet

    The 7" touchscreen tablet is provides in-cab computing capabilities for drivers.

Specifications

  • OS
  • Android
  • CPU
  • ARM Cortex A9 1GHz
  • Memory
  • 2G DDR3
  • Storage
  • 32G eMMC
  • Display
  • 7-inch LCD, Capacitive Touch
  • Communication
  • Wired: Ethernet/OBC
    Wireless: Cellular/GNSS/WLAN/Bluetooth/NFC
  • I/O Interface
  • Video in x 2
    Regular SD x 1
    Micro SIM Slot x 1
    USB Host x 1
    Micro USB (Slave) x 1
    DSUB Female connector (26 pins)
  • Power
  • 9~32V
  • Speaker
  • Speaker 2W x 1
  • Microphone
  • Microphone x 1
  • Button
  • Power/Home/Volume Up & Down/Reset
  • Environment
  • Operating temp -30℃ to 85℃
    Storage temp -40℃ to 85℃
  • IP level
  • IP65
