MS760

MS760

MS760

MS760

Feature

  • Android GMS Certified

    With Android GMS cetification, users are able to use Google service and app with the device as a smart phone.

  • In-cab & Portable Use

    With vehicle dock and removable battery design, it's able to support vehicle power input, offer rich I/O ports and operate either inside or outside the cab as a rugged mobile computer.

  • Rugged Vehicle Tablet

    The 7" touchscreen tablet connects to the OBC (On Board Computer) via Wi-Fi to obtain vehicle and positional information and runs fleet management applications.

Specifications

  • OS
  • Android
  • CPU
  • ARM Cortex A9 1GHz
  • Memory
  • 2G DDR3
  • Storage
  • 32G eMMC
  • Display
  • 7-inch LCD, 500nits, multi-touch (PCT)
  • RF
  • 3G/LTE/GNSS/Wi-Fi/Bluetooth/NFC
  • I/O Interface
  • POGO Pin for cradle x 1
    USB Host x 1
    Micro USB x 1
    Regular SD (Support SDXC) x 1
    Headphone x 1
    SIM slot x 1
    Video in x 1
  • Camera
  • 5M pixel (rear)
  • Power
  • 9~32V
  • Battery
  • Li-ion 2700mAh@7.4V
  • Sensor
  • Gryo 6-axis g-sensor, ambient light sensor
  • Speaker
  • Build-in speaker 2W x 1
  • Microphone
  • Microphone x 1
  • Barcode scanner
  • 1D/2D Scanner
  • Button
  • Power/Home/Volume Up & Down/Reset
  • Environment
  • Operating temp -20℃ to 70℃
    Storage temp -30℃ to 85℃
  • IP level
  • IP65
